AdoCId liquid quantitative, mechanical and electrical, pneumatic in one, electrical and pneumatic components used well-known brands, from the touch screen, PLC control, rational design, compact structure, beautiful appearance, with stable and reliable performance, filling accuracy, adaptability, simple operation, easy maintenance and so on. Suitable for a variety of viscous materials like perfume, toilet water, eye drops, nail polish, sesame oil, wine, liquor, battery liquid, detergent, soya sauce, tomato sauce etc.
Key Features :
- ±1% Filling accuracy on single dose.
- No bottle No filling system.
- Rigid vibration free construction for trouble free performance.
- Drain tray around machine platform.
- Pneumatic bottle stopping arrangement.
- Minimum change overtime, from one size to another container or fill size.
Optional Features :
- Acrylic cabinet
- Automatic chain washing system for conveyor belt
- Nitrogen Flushing
- Float tank (Holding tank) with or without stirrer
- PLC Based control Panel
Technical Specification :
| Model | CIALF - 100 | CIALF - 150 | CIALF - 200 |
| Output/Hour* | 2400 to 6000 | 3600 to 9000 | 5000 to 12,000 |
| Direction of Movement** | Left to Right | ||
| Number of head/syringe | 4 Nos. | 6 Nos. | 8 Nos. |
| Fill Size | 5 ml to 1000 ml*** | ||
| Electrical Specification | 1 HP / 415 Volts / 50 Hz. (1.5 HP if maximum volume is 1000 ml in single doze) |
1.5 Hp / 415 Volts / 50 Hz. | 2 HP / 415 Volts / 50 Hz. (2 HP if maximum volume is 1000 ml in single doze) |
| Height of Conveyor | 860 mm to 910 mm adjustable. | ||
| Machine Dimensions | 2135 mm (L) x 1150 mm (W) x 1610 mm (H) | 2135 mm (L) x 1350 mm (W) x 1610 mm (H) | |
| Case Dimensions | 2350 mm (L) x 1350 mm (W) x 1650 mm (H) | 2350 mm (L) x 1550 mm (W) x 1650 mm (H) | |
| Net Weight | 600 kgs. | 700 kgs. | 850 kgs. |
| Gross Dimensions | 850 kgs. | 950 kgs. | 1100 kgs. |
| Change parts required | (A) Syringes. (B) Nozzle (C) Inlet & outlet hose pipe | ||
- Depends on fill size/ nature & viscosity of liquid
- We can supply as per client's requirement
- with the help of change parts
