Salient Features :
- Tray Dryers Are Designed To Provide Uniform Drying Throughout The Material Being Dried, Ensuring Consistent Quality.
- Tray Dryers Are Versatile And Can Be Used For Drying A Wide Range Of Materials, Including Granules, Powders, And Herbs.
- Tray Dryers Can Dry Materials Quickly, Reducing The Time Required For The Drying Process.
- Tray Dryers Are Cost-Effective As They Require Low Maintenance And Have A Long Service Life.
- Tray Dryers Are Easy To Operate, And The Drying Process Can Be Controlled With Precision.
- Tray Dryers Are Easy To Clean And Sanitize, Making Them Suitable For Use In Industries Where Hygiene Is Crucial, Such As The Food And Pharmaceutical Industries.
- Tray Dryers Are Designed To Be Energy-Efficient, And The Use Of Hot Air As The Drying Medium Makes Them More Environmentally Friendly Than Other Drying Methods.
Technical Specifications :
| MODEL | CI - TD - 12 | CI - TD - 24 | CI - TD - 48 | CI - TD - 96 | CI - TD - 192 |
|---|---|---|---|---|---|
| Loading Capacity | 12 Trays | 24 Trays | 48 Trays | 96 Trays | 192 Trays |
| Number Of Doors | 1 Nos | 1 Nos | 1 Nos | 2 Nos | 2 Nos |
| Number Of Blowers | 1 Nos | 1 Nos | 1 Nos | 2 Nos | 4 Nos |
| Electrical Heating Load (kW) | 6 kW | 12 kW | 18 kW | 27 kW | 50 kW |
| Electric Motor (HP / kW / RPM) | 1 HP / 0.7 kW / 1440 RPM | 2 HP / 1.5 kW / 1440 RPM | 3 HP / 2.3 kW / 1440 RPM | 5 HP / 3.7 kW / 1440 RPM | 7.5 HP / 5.5 kW / 1440 RPM |
| Steam Heater Coils (Nos) | 2 Nos | 2 Nos | 2 Nos | 2 Nos | 2 Nos |
| Steam Pressure (Kg / cm2) | 3.3 Kg / cm2 | 3.3 Kg / cm2 | 3.3 Kg / cm2 | 3.3 Kg / cm2 | 3.3 Kg / cm2 |
| Steam Consumption (LBS / Hour) | 25 LBS / Hour | 45 LBS / Hour | 60 LBS / Hour | 80 LBS / Hour | 120 LBS / Hour |
| Insulation (mm)100°C / 200°C / 300°C | 50 / 75 / 75 mm | 50 / 75 / 75 mm | 50 / 75 / 75 mm | 50 / 75 / 75 mm | 50 / 75 / 75 mm |
| Tray Loading | Rack System | Rack System | 1 Trolley | 2 Trolley | 4 Trolley |
| Trolley Dimension (mm) | Fixed Racks | Fixed Racks | 840 X 960 X 1780 | 840 X 960 X 1780 | 840 X 960 X 1780 |
| Tray Dimension (mm) | 406 mm X 812 mm X 31 mm / 16” Inch X 32” Inch X 1+¼” Inch | ||||
| Electrical Power Supply | 230 Volts ± 10% Or 440 Volts ± 10% / 50 Hz Or 60 Hz / 3 Φ Phase / A.C. Power Supply | ||||
