Tablet Compression Rotary Machine Manufacturer, Exporter in India

Robust with high quality Engineering
Turret of SG IRON 500/7 Graded Casting
Medium batch production
Maximum output upto 216000 tablets per hour (for 45 Station)
Tablets of upto 23 mm Diameter for 'D' Tooling and 16 mm Diameter for 'B' Tooling
Safe / Simple to operate and easy to maintain
Designed as per cGMP standards

Type	CIB4-D-27	CIB4-35
No. of station	27	35
Type of tooling	D	B
Output tablets / hour * (Single Layer)	58,320 to 129,000	75,600 to 168,000
Maximum operating pressure (main)	10 Tons	6.5 Tons
Maximum tablet diameter	23 mm (25 mm on Demand)	16 mm
Maximum depth of fill	20 mm	17.5 mm
Upper punch penetration	1.5 to 8 mm
Main electric motor	3.70 kW/5hp, 1440 RPM 415 V, 50 Hz., 3Phase
Overall dimensions (cm)	105 * 106 * 181H
Case Dimension (cm)	130 * 131 * 200H
Net weight	1490 kg
Grass Weight	1680 kg

Hand wheel provided.
Turret of SG IRON 500/7 Graded Casting.
Main Operating Pressure up to 10 Tons (For 12 Station - Up to 12 Tons).
Sturdy and easy fit Feed Frame (Gravity Feeder) of Gun Metal.
Central oil lubrication system with manual hand pump.
Cam tracks and pressure rolls made out of alloy steel for maximum wear resistance and long life.
Worm is made of Phosphor Bronze.
Ease of operation and maintenance.
Maximum 42 RPM of Turret.
Variable speed pulley drive (For 12 Station Fixed Pulley with Two different speeds).
Mechanical Overload Pressure release arrangement.

Model	CI-D-16	CI-D-20	CI - 12
Tooling	D	D	Special
No. of Station	16	20	12
Maximum Operating Pressure	10 Tons	10 Tons	12 Tons
Maximum Tablet Diameter	23 mm (25 mm on Demand)	23 mm (25 mm on Demand)	40 mm
Maximum Depth of fill	20 mm	20 mm	30 mm
Output Tablets/Hour *	14,400 to 40,320	18,000 to 50,400	10,800 & 15,840
Electric Motor	2 Hp/960 RPM	2 Hp/960 RPM	5 Hp/1440 RPM
