Key Features :
- No container no cap arrangement.
- Single motor synchronizes conveyor, star wheel & platform turret.
- Adjustable height of conveyor belt.
- All contact parts are made out of stainless steel.
- Pick & Place arrangement.
- Torque adjustable.
- Low noise level, low power consumptions.
Optional Features :
- No cap no container arrangement.
- Motorized Height Adjustments.
- Acrylic cabinet.
- Safety Guard for Operation and Protection.
- Specially designed hopper is to increase storage capacity of bowl.
Technical Specification :
| Output / Hour * | 3600 to 6000 Bottles | 3600 to 9000 Bottles | 4000 to 12,000 Bottles |
| Direction of Movement | Left to Right | ||
| Number of head ** | 4 Nos. | 6 Nos. | 8 Nos. |
| Electrical Specification | Main Motor : 1.5 HP / 415 Volts / 50 Hz. | ||
| Cap feeding Bowl : 0.25 HP / 415 Volts / 50 Hz. | |||
| Height of Conveyor | 860 mm to 910 mm | ||
| Machine Dimensions | 2135 mm (L) x 1120 mm (W) x 2250 mm (H) Approx | 2135 mm (L) x 1120 mm (W) x 2250 mm (H) Approx | |
| Case Dimensions | 2650 mm (L) x 1250 mm (W) x 2250 mm (H) Approx | 2650 mm (L) x 1320 mm (W) x 2250 mm (H) Approx | |
| Net Weight | 900 Kgs. Approx | 1200 Kgs. Approx | |
| Gross Weight | 1250 Kgs. Approx | 1300 Kgs. Approx | 1550 Kgs. Approx |
| Change parts required |
(A) Container: Star Wheel, Center guide, Feed Worm. (B) Cap: Die, Delivery chute, bowl. |
||
- Depends on Cap.Size
- We can supply as per client's requirement
