Key Features :
- Direct gear drive
- Length can be made as per customer requirement
- PVC black and white board as per GMP norms
- UHMW self lubrication guide below chain
- S.S. Elegantly matt finishing
- Adjustable height of conveyor belt, to align with other machine of the line
- Self alignment bearing for easy maintenance
- Rigid vibration free construction for trouble free performance
Optional Features :
- Castor wheel with lock.
- A/c frequency variable drive
Demonstration Available :
| Direction of Movement | Left to Right | |
| Output | Up to 100 Containers/minute | Up to 150 Containers/minute |
| Number of Operator | Four (2x2, Two Side Seated) | Six (3x2, Two Side Seated)/td> |
| Number Characteristics | 0.5 HP/220 Volts / 50 Hz. | 0.5 HP/220 Volts / 50 Hz. |
| Height of Conveyor | 860mm to 910mm | |
| Machine Dimensions | 1860mm (L) x 700mm (W) x 1525mm (H) | 2440mm (L) x 700mm (W) x 1525mm (H) |
| Case Dimensions | 2150mm (L) x 950mm (W) x 1750mm (H) | 2750mm (L) x 950mm (W) x 1750mm (H) |
| Net Weight | 200 kgs. | 275 kgs. |
| Gross Weight | 425 kgs. Approx. | 525 kgs. Approx. |
