Bottle Filling Machine, Automatic Bottle Filling Machine Manufacturer in Ahmedabad

"GMP" Model based on advanced technology.
Single Operator for Two Operations.
Less Floor Area - as both the sections driven by one motor.
No Contamination as immediate sealing of filled bottles.
Accuracy ±1% due to piston dozing principle.
Centralized Volume Adjustment System.
No Bottle No Fill for individual head, hence no spillages.
Placing of Cap Feeder Outside Monoblock - avoid entering of dust in it.
Fewer Caps in chute automatically stop the machine.
Additional Sensors for Minimum and Maximum Level of Cap in chute which automatically start and stop rotary cap feeder to avoid damage of caps during rotation and wastage of energy.
Better finish imported polished, laminated S.S. sheet used.
Electronic liquid level controller and pneumatically controlled control valve.
Drip trays under the conveyor.
Self Lubricating UHMW-PE Guide profile for Low friction wear surface, smooth and noiseless conveying.
Universal coupling for quick and easy setting of In-feed worm.
Safety Guard for Operation and Protection.
Electronic Sensor at out feed for Bottle Jamming.

Model	CIM - 6/6	CIM - 8/8	CIM - 16/8
Output / Hour	2500 to 7500 Bottles	4000 to 10,000 Bottles	7000 to 14500 Bottles
Number of head/syringe	6	8	16
Number of head/sealing	6	8	8
Direction of movement	Left to Right
File Size	30 ml. to 200 ml.
Electrical Specification	Main Machine	3 HP / 415 Volts / 50 Hz.	5 HP / 415 Volts / 50 Hz.
	Oriental bowl	0.25 HP / 415 Volts / 50 Hz.	0.5 HP / 415 Volts / 50 Hz.
	Conveyor	0.5 HP / 415 Volts / 50 Hz.	0.75 HP / 415 Volts / 50 Hz.
Height of Conveyor	910 mm to 960 Adjustable
Machine Dimensions	3050 mm (L) x 1400 mm (W) x 2200 mm (H)	3660 mm (L) x 1700 mm (W) x 2400 mm (H)
Case Dimensions	3250 mm (L) x 1600 mm (W) x 2200 mm (H)	3850 mm (L) x 1900 mm (W) x 2400 mm (H)
Net Weight	2500 Kgs.	2650 Kgs.	4200 Kgs.
Gross Weight	3000 Kgs.	3250 Kgs.	5000 Kgs.
Change parts required	(A) Container: Star Wheel, Back guide, Feed Worm, Nozzle (B) Cap: Die, Delivery chute, bowl. (C) Syringes (if volume higher/lower then above specification)

Monoblock
