Key Features :
- Geneva Mechanism.
- Four inner (Included one air wash) & one outer.
- Sequence of washes to customer's choice.
- Easy operation.
- Stationary nozzles eliminate contamination of water cycles.
- Easy loading and unloading.
- Individual solenoid valve for each washing sequence that eliminates carbon plate and other accessories reduces leakage and maintenance to minimum.
- Higher capacity centrifugal pumps to wash bigger bottles (500 & 1000 ml.).
- The stationary nozzles avoid chipping of bottle necks.
- Pumps and tanks are mounted on portable stand for easy maintenance.
- Bottle guide system especially for lightweight bottle.
- Pumps and Tanks are mounted on portable stand for easy maintenance.
- Separate panel control to avoid any short circuit due to spraying of water.
- S.S. glycerin fill pressure meter.
Technical Specification :
| Model | |||
| CIWM - 64 | CIWM - 96 | ||
| Output / Hour | 2600 to 6000 Nos. | 4300 to 9000 Nos. | |
| No. of Container Holder | 64 | 94 | |
| Direction of Movement | Clock wise | ||
| Electrical Specification | Main Motor | 0.5 HP / 415 Volts / 50 Hz. | |
| Pump Two Nos. | 1HP X 2 = 2 HP / 415 Volts / 50 HZ | ||
| Electric Heater | 3 Kw. | ||
| Tank Capacity | 75 Ltrs. S.S. 304 (2 Nos.) | ||
| Wash Cycle | 4 inner + 1 Outer | ||
| Working heights | 860 to 910 mm | ||
| Machine Dimensions (In mm) | 1500 (L) X 1750 (W) X 1300 (H) | 1500 (L) X 1750 (W) X 1300 (H) | |
| Case Dimensions (In mm) Two Cases | Machine | 1600 (L) X 1600 (W) X 1550 (H) | 1600 (L) X 1600 (W) X 1550 (H) |
| Tanks | 1550 (L) X 1000 (W) X 1550 (H) | 1550 (L) X 1000 (W) X 1550 (H) | |
| Net Weight | 450 Kgs. | 550 Kgs. | |
| Gross Weight | 750 Kgs. | 900 Kgs. | |
| Change parts required | (A) Neck Dia: Bottle holding pocket. | ||
| (B) Flat Container: Special type of cup. | |||
- Depends on Cap.Size
- We can supply as per client's requirement
